Babboe Carve Mountain

The best of two worlds: the stability of a tricycle combined with the manoeuvrability of a two-wheeled cargo bike. Thanks to the 'carve mechanism' the box moves along the bends while cycling, making you cycle like on a two-wheeler and providing excellent road holding.

The electric Babboe Carve Mountain features state-of-the-art pedal assistance, giving you a natural, smooth cycling experience. Transport your baby in safety with the special Maxi-Cosi carrier, with room for two other small children besides. You can add a second bench to your Babboe Carve Mountain, to create four seats in the cargo bike.


  • Agile cargo bike with the stability of a three-wheeler
  • Front wheels and box both tilt when taking bends
  • Powerful motor and smooth stepless shifting

Popular

Battery location Under the bench
Motor position Midmotor
Force (Nm) 70
Type of gear Stepless hub
Number of children 1 child, 2 children
Seat belts 2 three-point seat belts
Charging time 4-6 hours
Action radius (km) 40-60
Environment Rolling roads, Hilly roads
Numbers of gears Infinit

Accu

Charging in cargo bike possible Yes
Battery charger 42V 2.17A
Battery location Under the bench
Removable battery Yes
Battery type Lithium-ion
Charging time 4-6 hours
Action radius (km) 40-60

Comfort

Frame material Steel
Luggage rack load (kg) 20
Way of parking With the double standard
Adjustable saddle Yes
Minimum body height 1.57
Seatpost Unsprung
Sitting posture Sportive
Steering dampers No
Adjustable steering wheel Yes
Luggage carrier No
Suitable for Maxi-Cosi Yes
Pedals Yes
Environment Rolling roads, Hilly roads

Dimensions

Width cargo bike (cm) 85
Height cargo bike (cm) 110
Length cargo bike (cm) 216
Width box (cm) 68
Height box (cm) 58
Length box (cm) 109
Wheelbase (cm) 130

Display

Brand display Yamaha
Support modes 4
Position on the handlebar Left
Detachable display No
Display type LED
Micro USB No

Electric

Motor 36V 250W maintenance-free motor
Motor position Midmotor
Engine sound Extremely quiet
Motor technology Yamaha
Force (Nm) 70
Type of sensor Power and speed
Maximum speed with support (km/h) 25
Walk assist Yes

Gears

Brand gear Enviolo NuVinci
Type of gear Stepless hub
Drive type Chain
Numbers of gears Infinit

General

Brand Babboe
Folding benches No
Number of benches 1
Box load capacity (kg) 80
Electric cargo bike Electric cargo bike
Frame Extra sturdy frame with shockproof powder coating, treated on the inside to prevent rusting.
Frame color Anthracite
Frame size (cm) 50
Frame type Low entry
Number of children 1 child, 2 children
Saddle load (kg) 100
Material box European beech wood
step for children Yes
Box volume (L) 350
Weight (kg) 69
Water resistant No

Lighting

Brand headlight AXA
Brand rear light AXA
Lighting LED lighting via battery (front and rear)

Safety

Seat belts 2 three-point seat belts
Cargo bike certification Yes
Lock brand Abus
Suitable for plug-in chain Yes
ART lock certification Yes
Tilt stops Yes

Warranty

Warranty battery 2 years
Warranty box 1 year
Warranty frame 5 years
Warranty engine 2 years
Warranty parts 2 years

Wheels

Anti-puncture tires Yes
Rims Double walled front and rear rims
Spokes Extra sturdy spokes
Tire pressure (bar) 4
Bicycle tire brand CST Pro Brooklyn
Tire size rear (inch) 26
Tire size front (inch) 20
Product specifications Download (.pdf)
User manual Download (.pdf)
User manual 2 Download (.pdf)
Safety data sheet Download (.pdf)
Declaration of Conformity (DoC) Download (.pdf)
Please accept marketing-cookies to watch this video.
The Babboe cargo bikes come with a 5-year warranty on the frame and a 2-year warranty on non-wearing parts (brakes and gears). You can find the warranty periods per part in the warranty conditions.
